OBATABITECH / DEVICE DOSSIER
CPU / Intel
Core Ultra 9 285K
Harga referensiRp 10.899.000
Socket CPULGA 1851Jumlah Core24Jumlah Thread24Base Clock3.70 GHz (P-Core) / 3.20 GHz (E-Core)
Kembali ke katalogIntel Core Ultra 9 285K
Spesifikasi perangkat /
Data teknis disusun per sistem agar lebih cepat dipindai dan dibandingkan.
Identitas
- Family SKU
- Arrow Lake-S (LGA 1851)
Performa
- Prosesor
- 24 Cores (8 Lion Cove P-Core + 16 Skymont E-Core, No HT), 24 Threads, Base 3.70 GHz (P-Core) / 3.20 GHz (E-Core), Boost 5.70 GHz (Thermal Velocity Boost) / 4.60 GHz (E-Core), L3 36 MB Intel Smart Cache
- Grafis
- Intel Graphics (4 Xe Cores R24, Dynamic up to 2.0 GHz) + NPU 13 TOPS
- Socket CPU
- LGA 1851
- Chipset Kompatibel
- Intel Z890, B860, H870
- Jumlah Core
- 24
- Jumlah Thread
- 24
- Base Clock
- 3.70 GHz (P-Core) / 3.20 GHz (E-Core)
- Boost / Turbo Clock
- 5.70 GHz (Thermal Velocity Boost) / 4.60 GHz (E-Core)
- L1 Cache
- 2.4 MB (8 x 112 KB P-Core + 16 x 96 KB E-Core)
- L2 Cache
- 40 MB (8 x 3 MB P-Core + 4 x 4 MB E-Core clusters)
- L3 Cache
- 36 MB Intel Smart Cache
- Jalur PCIe
- PCIe 5.0 (20 Lanes: 16 GPU + 4 NVMe) + PCIe 4.0 (4 Lanes) = 24 Lanes
- Litografi / Proses
- TSMC N3B (Compute Tile 3nm) + TSMC N6 (SoC/IO)
- TDP / Konsumsi Daya
- 125W Base (PL1) / 250W Max Turbo (PL2)
- Memori
- DDR5-6400 (CUDIMM / UDIMM Dual-channel, Max 192 GB) - Tanpa DDR4
Lainnya
- Rilis
- 2024-10-24
- Sumber harga
- Intel Official Indonesia
- Harga diperbarui
- 2026-09-07
- integrated graphics
- Intel Graphics (4 Xe Cores R24, Dynamic up to 2.0 GHz) + NPU 13 TOPS
- memory channels
- 2
- memory max gb
- 192
- power limit w
- 250
- tdp w
- 125
