OBATABITECH / DEVICE DOSSIER
GPU / AMD
Instinct MI300X
Harga referensiRp 350.000.000
Chip GPUMI300X (Aqua Vanjar)Kapasitas VRAM192 GBTipe Memori VRAMHBM3 (8 Stacks, 12-Hi 24GB per stack)Lebar Bus Memori8192-bit
Kembali ke katalogAMD Instinct MI300X
Spesifikasi perangkat /
Data teknis disusun per sistem agar lebih cepat dipindai dan dibandingkan.
Identitas
- Family SKU
- CDNA 3 (Datacenter AI/HPC) (MI300X (Aqua Vanjar))
Performa
- Prosesor
- CDNA 3 (Datacenter AI/HPC) (MI300X (Aqua Vanjar)), 19456 Stream Processors (304 Compute Units), Base 1700 MHz, Boost 2100 MHz
- Grafis
- AMD Instinct MI300X (192 GB HBM3 (8 Stacks, 12-Hi 24GB per stack))
- Chip GPU
- MI300X (Aqua Vanjar)
- Jumlah Core
- 19456 Stream Processors (304 Compute Units)
- Tensor Cores / AI
- 1216 Matrix Cores (CDNA 3 with FP8, FP16, BF16, TF32, INT8)
- Ray Tracing Cores
- None (Akselerator AI Murni)
- Base Clock
- 1700 MHz
- Boost / Turbo Clock
- 2100 MHz
- L2 Cache
- 256 MB AMD Infinity Cache on-package
- Jalur PCIe
- OAM / PCIe 5.0 x16 + 8x Infinity Fabric Links (896 GB/s)
- Kapasitas VRAM
- 192 GB
- Tipe Memori VRAM
- HBM3 (8 Stacks, 12-Hi 24GB per stack)
- Lebar Bus Memori
- 8192-bit
- Bandwidth Memori
- 5300.0 GB/s (5.3 TB/s)
- Litografi / Proses
- TSMC 5nm (8 XCDs) + TSMC 6nm (4 IODs) 3D Hybrid Bonding
- TDP / Konsumsi Daya
- 750W TDP
- Konektor Daya
- Direct OAM Baseboard Power / Server Busbar
- Ukuran Slot / Dimensi
- OAM Mezzanine Module / 8-GPU Universal Baseboard (UBB)
- Memori
- 192 GB HBM3 (8 Stacks, 12-Hi 24GB per stack), 8192-bit, 5300.0 GB/s (5.3 TB/s) (256 MB AMD Infinity Cache on-package)
Layar & kamera
- Layar
- None (Enterprise AI Datacenter Headless)
Lainnya
- Rilis
- 2023-12-06
- Sumber harga
- Enterprise Supercomputing Server Distributor
- Harga diperbarui
- 2026-09-07
- gpu board power w
- 750
- gpu vram gb
- 192
