OBATABITECH / DEVICE DOSSIER
GPU / NVIDIA
H100 Tensor Core GPU 80GB PCIe
Harga referensiRp 490.000.000
Chip GPUGH100-820-A1Kapasitas VRAM80 GBTipe Memori VRAMHBM2e / HBM3 (5 Stacks)Lebar Bus Memori5120-bit
Kembali ke katalogNVIDIA H100 Tensor Core GPU 80GB PCIe
Spesifikasi perangkat /
Data teknis disusun per sistem agar lebih cepat dipindai dan dibandingkan.
Identitas
- Family SKU
- Hopper Datacenter (GH100-820-A1)
Performa
- Prosesor
- Hopper Datacenter (GH100-820-A1), 14592 CUDA Cores (114 SMs), Base 1095 MHz, Boost 1755 MHz
- Grafis
- NVIDIA H100 Tensor Core GPU 80GB PCIe (80 GB HBM2e / HBM3 (5 Stacks))
- Chip GPU
- GH100-820-A1
- Jumlah Core
- 14592 CUDA Cores (114 SMs)
- Tensor Cores / AI
- 456 4th-Gen Tensor Cores with Transformer Engine
- Ray Tracing Cores
- None
- Base Clock
- 1095 MHz
- Boost / Turbo Clock
- 1755 MHz
- L2 Cache
- 50 MB L2 Cache
- Jalur PCIe
- PCIe 5.0 x16 (128 GB/s) + Dual NVLink Bridge (600 GB/s)
- Kapasitas VRAM
- 80 GB
- Tipe Memori VRAM
- HBM2e / HBM3 (5 Stacks)
- Lebar Bus Memori
- 5120-bit
- Bandwidth Memori
- 2000.0 GB/s (2.0 TB/s)
- Litografi / Proses
- TSMC 4N (Custom 5nm Hopper)
- TDP / Konsumsi Daya
- 350W TDP
- Konektor Daya
- 1x 16-pin 12V-2x6 / 12VHPWR
- Ukuran Slot / Dimensi
- Dual-Slot Passive Server Card
- Memori
- 80 GB HBM2e / HBM3 (5 Stacks), 5120-bit, 2000.0 GB/s (2.0 TB/s) (50 MB L2 Cache)
Layar & kamera
- Layar
- None (Headless AI/HPC Datacenter)
Lainnya
- Rilis
- 2022-09-20
- Sumber harga
- Enterprise AI Hardware Quotation Indonesia
- Harga diperbarui
- 2026-09-07
- gpu board power w
- 350
- gpu vram gb
- 80
