OBATABITECH / DEVICE DOSSIER
GPU / Intel
Arc A580
Harga referensiRp 3.100.000
Chip GPUAlchemist ACM-G10Kapasitas VRAM8 GBTipe Memori VRAMGDDR6Lebar Bus Memori256-bit
Kembali ke katalogIntel Arc A580
Spesifikasi perangkat /
Data teknis disusun per sistem agar lebih cepat dipindai dan dibandingkan.
Identitas
- Family SKU
- Xe-HPG (Alchemist) (Alchemist ACM-G10)
Performa
- Prosesor
- Xe-HPG (Alchemist) (Alchemist ACM-G10), 3072 Shading Units (24 Xe Cores), Base 1700 MHz, Boost 2000 MHz
- Grafis
- Intel Arc A580 (8 GB GDDR6)
- Chip GPU
- Alchemist ACM-G10
- Jumlah Core
- 3072 Shading Units (24 Xe Cores)
- Tensor Cores / AI
- 384 Intel XMX Engines (Xe Matrix Extensions)
- Ray Tracing Cores
- 24 Ray Tracing Units
- Base Clock
- 1700 MHz
- Boost / Turbo Clock
- 2000 MHz
- L2 Cache
- 8.0 MB L2 Cache
- Jalur PCIe
- PCIe 4.0 x16 (Resizable BAR wajib aktif)
- Kapasitas VRAM
- 8 GB
- Tipe Memori VRAM
- GDDR6
- Lebar Bus Memori
- 256-bit
- Bandwidth Memori
- 512.0 GB/s (16.0 Gbps)
- Litografi / Proses
- TSMC N6 (6nm)
- TDP / Konsumsi Daya
- 185W TBP
- Konektor Daya
- 2x 8-pin PCIe
- Ukuran Slot / Dimensi
- Dual-Slot (2-slot), 260 mm
- Memori
- 8 GB GDDR6, 256-bit, 512.0 GB/s (16.0 Gbps) (8.0 MB L2 Cache)
Layar & kamera
- Layar
- 3x DisplayPort 2.0 (UHBR 10), 1x HDMI 2.1
Lainnya
- Rilis
- 2023-10-10
- Sumber harga
- Authorized Retailer Indonesia 2024-2026
- Harga diperbarui
- 2026-09-07
- gpu board power w
- 185
- gpu length mm
- 260
- gpu slot width
- 2-slot
- gpu vram gb
- 8
