OBATABITECH / DEVICE DOSSIER
GPU / Intel
Arc A770 16GB
Harga referensiRp 5.600.000
Chip GPUAlchemist ACM-G10Kapasitas VRAM16 GBTipe Memori VRAMGDDR6Lebar Bus Memori256-bit
Kembali ke katalogIntel Arc A770 16GB
Spesifikasi perangkat /
Data teknis disusun per sistem agar lebih cepat dipindai dan dibandingkan.
Identitas
- Family SKU
- Xe-HPG (Alchemist) (Alchemist ACM-G10)
Performa
- Prosesor
- Xe-HPG (Alchemist) (Alchemist ACM-G10), 4096 Shading Units (32 Xe Cores), Base 2100 MHz, Boost 2400 MHz
- Grafis
- Intel Arc A770 16GB (16 GB GDDR6)
- Chip GPU
- Alchemist ACM-G10
- Jumlah Core
- 4096 Shading Units (32 Xe Cores)
- Tensor Cores / AI
- 512 Intel XMX Engines
- Ray Tracing Cores
- 32 Ray Tracing Units
- Base Clock
- 2100 MHz
- Boost / Turbo Clock
- 2400 MHz
- L2 Cache
- 16.0 MB L2 Cache
- Jalur PCIe
- PCIe 4.0 x16 (ReBAR wajib)
- Kapasitas VRAM
- 16 GB
- Tipe Memori VRAM
- GDDR6
- Lebar Bus Memori
- 256-bit
- Bandwidth Memori
- 560.0 GB/s (17.5 Gbps)
- Litografi / Proses
- TSMC N6 (6nm)
- TDP / Konsumsi Daya
- 225W TBP
- Konektor Daya
- 1x 6-pin, 1x 8-pin PCIe
- Memori
- 16 GB GDDR6, 256-bit, 560.0 GB/s (17.5 Gbps) (16.0 MB L2 Cache)
Layar & kamera
- Layar
- 3x DisplayPort 2.0, 1x HDMI 2.1
Lainnya
- Rilis
- 2022-10-12
- Sumber harga
- Intel Limited Edition SRP Indonesia
- Harga diperbarui
- 2026-09-07
- gpu board power w
- 225
- gpu length mm
- 267
- gpu slot width
- 2-slot
- gpu vram gb
- 16
