OBATABITECH / DEVICE DOSSIER
GPU / Intel
Arc B580
Harga peluncuran IndonesiaRp 4.500.000
Chip GPUBattlemage BMG-G21Kapasitas VRAM12 GBTipe Memori VRAMGDDR6Lebar Bus Memori192-bit
Kembali ke katalogIntel Arc B580
Spesifikasi perangkat /
Data teknis disusun per sistem agar lebih cepat dipindai dan dibandingkan.
Identitas
- Family SKU
- Xe2-HPG (Battlemage) (Battlemage BMG-G21)
Performa
- Prosesor
- Xe2-HPG (Battlemage) (Battlemage BMG-G21), 2560 Shading Units (20 Xe2 Cores), Base 2670 MHz, Boost 2850 MHz
- Grafis
- Intel Arc B580 (12 GB GDDR6)
- Chip GPU
- Battlemage BMG-G21
- Jumlah Core
- 2560 Shading Units (20 Xe2 Cores)
- Tensor Cores / AI
- 160 Intel XMX Engines (2nd Gen Xe2)
- Ray Tracing Cores
- 20 Ray Tracing Units (2nd Gen)
- Base Clock
- 2670 MHz
- Boost / Turbo Clock
- 2850 MHz
- L2 Cache
- 16.0 MB L2 Cache
- Jalur PCIe
- PCIe 4.0 x8
- Kapasitas VRAM
- 12 GB
- Tipe Memori VRAM
- GDDR6
- Lebar Bus Memori
- 192-bit
- Bandwidth Memori
- 456.0 GB/s (19.0 Gbps)
- Litografi / Proses
- TSMC N4P (4nm)
- TDP / Konsumsi Daya
- 190W TBP
- Konektor Daya
- 1x / 2x 8-pin PCIe
- Ukuran Slot / Dimensi
- Dual-Slot (2-slot), 245 mm
- Memori
- 12 GB GDDR6, 192-bit, 456.0 GB/s (19.0 Gbps) (16.0 MB L2 Cache)
Layar & kamera
- Layar
- 3x DisplayPort 2.1 (UHBR 13.5), 1x HDMI 2.1
Lainnya
- Rilis
- 2024-12-13
- Sumber harga
- Intel MSRP Peluncuran Resmi ($249 USD)
- Harga diperbarui
- 2026-09-07
- gpu board power w
- 190
- gpu length mm
- 245
- gpu slot width
- 2-slot
- gpu vram gb
- 12
