OBATABITECH / DEVICE DOSSIER
GPU / NVIDIA
GeForce RTX 4070 Super
Harga referensiRp 10.900.000
Chip GPUAD104-350-A1Kapasitas VRAM12 GBTipe Memori VRAMGDDR6X (Micron)Lebar Bus Memori192-bit
Kembali ke katalogNVIDIA GeForce RTX 4070 Super
Spesifikasi perangkat /
Data teknis disusun per sistem agar lebih cepat dipindai dan dibandingkan.
Identitas
- Family SKU
- Ada Lovelace (AD104-350-A1)
Performa
- Prosesor
- Ada Lovelace (AD104-350-A1), 7168 CUDA Cores (56 SMs), Base 1980 MHz, Boost 2475 MHz
- Grafis
- NVIDIA GeForce RTX 4070 Super (12 GB GDDR6X (Micron))
- Chip GPU
- AD104-350-A1
- Jumlah Core
- 7168 CUDA Cores (56 SMs)
- Tensor Cores / AI
- 224 Tensor Cores (4th Gen)
- Ray Tracing Cores
- 56 RT Cores (3rd Gen)
- Base Clock
- 1980 MHz
- Boost / Turbo Clock
- 2475 MHz
- L2 Cache
- 48 MB L2 Cache
- Jalur PCIe
- PCIe 4.0 x16
- Kapasitas VRAM
- 12 GB
- Tipe Memori VRAM
- GDDR6X (Micron)
- Lebar Bus Memori
- 192-bit
- Bandwidth Memori
- 504.2 GB/s (21.0 Gbps)
- Litografi / Proses
- TSMC 4N (5nm)
- TDP / Konsumsi Daya
- 220W TGP
- Konektor Daya
- 1x 16-pin (12V-2x6 / 12VHPWR), adapter 2x 8-pin
- Memori
- 12 GB GDDR6X (Micron), 192-bit, 504.2 GB/s (21.0 Gbps) (48 MB L2 Cache)
Layar & kamera
- Layar
- 3x DisplayPort 1.4a, 1x HDMI 2.1a
Lainnya
- Rilis
- 2024-01-17
- Sumber harga
- Authorized Reseller Indonesia 2024-2026
- Harga diperbarui
- 2026-09-07
- gpu board power w
- 220
- gpu length mm
- 242
- gpu slot width
- 2-slot
- gpu vram gb
- 12
