MSI MAG B650 TOMAHAWK WIFI — Technologia Universe

1 / 5

Kembali ke katalogMSI MAG B650 TOMAHAWK WIFI

Tag

motherboardmsiam5b650ddr5tomahawk

TECHNICAL INDEX

Spesifikasi perangkat

Data teknis disusun per sistem agar lebih cepat dipindai dan dibandingkan.

Prosesor: AMD B650 (Socket AM5 (LGA 1718)), ATX (305 x 244 mm), VRM 14+2+1 Duet Rail Power System (80A SPS)
Socket CPU: Socket AM5 (LGA 1718)
Chipset Kompatibel: AMD B650
Form Factor Motherboard: ATX (305 x 244 mm)
Kecepatan RAM Maksimal: DDR5-7600+ (OC) / AMD EXPO & Intel XMP
Jumlah Port SATA: 6
Fasa VRM & Desain Daya: 14+2+1 Duet Rail Power System (80A SPS)
Konektor Daya CPU: 2x 8-pin EPS 12V
Tipe Memori (RAM): DDR5
Jumlah Slot DIMM: 4x DDR5 DIMM (Dual Channel)
Kapasitas RAM Maksimal: 192 GB (4x 48 GB)
Slot Ekspansi PCIe: 1x PCIe 4.0 x16 (Steel Armor), 1x PCIe 4.0 x16 @ x4, 1x PCIe 3.0 x1
Slot M.2 NVMe: 3x M.2 (all PCIe 4.0 x4 with M.2 Shield Frozr)
Port SATA 6Gb/s: 6x SATA 6Gb/s (RAID 0, 1, 10)
Port I/O Panel Belakang: 1x USB 3.2 Gen 2x2 Type-C (20Gbps), 3x USB 3.2 Gen 2, 4x USB 3.2 Gen 1, 2x USB 2.0, HDMI 2.1, DisplayPort 1.4
Jaringan (LAN & Wi-Fi): Realtek RTL8125BG 2.5GbE LAN + AMD Wi-Fi 6E + Bluetooth 5.3
Subsistem Audio: Realtek ALC4080 7.1 HD Audio + Audio Boost 5
Fitur Kemudahan Rakit & Diagnostik: Flash BIOS Button, EZ Debug LED, Extended Heatsink Design, Pre-installed I/O Shield
Memori: 4x DDR5 DIMM (Dual Channel) DDR5, Max 192 GB (4x 48 GB) (DDR5-7600+ (OC) / AMD EXPO & Intel XMP)
Penyimpanan: 3x M.2 (all PCIe 4.0 x4 with M.2 Shield Frozr), 6x SATA 6Gb/s (RAID 0, 1, 10)

Konektivitas: Realtek RTL8125BG 2.5GbE LAN + AMD Wi-Fi 6E + Bluetooth 5.3, 1x USB 3.2 Gen 2x2 Type-C (20Gbps), 3x USB 3.2 Gen 2, 4x USB 3.2 Gen 1, 2x USB 2.0, HDMI 2.1, DisplayPort 1.4

Rilis: 2024-01-01
Sumber harga: Authorized Distributor Indonesia 2024-2026
Harga diperbarui: 2026-09-07
cpu bios update notes: Ryzen 8000/9000 may require BIOS update on a 600-series board; verify motherboard revision and CPU Support List.
cpu support generations: AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series
m2 slots detail: all PCIe 4.0 x4 with M.2 Shield Frozr
memory max gb: 192
memory module form factor: UDIMM
memory registered support: no
memory slots total: 4
pcie slots detail: 1x PCIe 4.0 x16 (Steel Armor), 1x PCIe 4.0 x16 @ x4, 1x PCIe 3.0 x1
