Kembali ke katalogASUS ROG STRIX B650E-E GAMING WIFI

Tag

motherboardasusam5b650epcie5rog-strix

TECHNICAL INDEX

Spesifikasi perangkat

Data teknis disusun per sistem agar lebih cepat dipindai dan dibandingkan.

Prosesor: AMD B650E (Extreme) (Socket AM5 (LGA 1718)), ATX (305 x 244 mm), VRM 16+2 Power Stages (70A Smart Power Stage)
Socket CPU: Socket AM5 (LGA 1718)
Chipset Kompatibel: AMD B650E (Extreme)
Form Factor Motherboard: ATX (305 x 244 mm)
Kecepatan RAM Maksimal: DDR5-8000+ (OC) / AMD EXPO & Intel XMP
Jumlah Port SATA: 4
Fasa VRM & Desain Daya: 16+2 Power Stages (70A Smart Power Stage)
Konektor Daya CPU: 2x 8-pin ProCool II EPS 12V
Tipe Memori (RAM): DDR5
Jumlah Slot DIMM: 4x DDR5 DIMM (Dual Channel)
Kapasitas RAM Maksimal: 192 GB (4x 48 GB)
Slot Ekspansi PCIe: 2x PCIe 5.0 x16 (x16 or x8/x4 mode), 1x PCIe 4.0 x16 @ x4
Slot M.2 NVMe: 4x M.2 (2x PCIe 5.0 x4 + 2x PCIe 4.0 x4 with massive thermal armor)
Port SATA 6Gb/s: 4x SATA 6Gb/s (RAID 0, 1, 10)
Port I/O Panel Belakang: 1x USB 3.2 Gen 2x2 Type-C, 1x USB 3.2 Gen 2 Type-C, 10x USB Type-A, HDMI 2.1, DisplayPort 1.4
Jaringan (LAN & Wi-Fi): Intel 2.5GbE LAN + Wi-Fi 6E (802.11ax) + Bluetooth 5.3
Subsistem Audio: ROG SupremeFX ALC4080 + Savitech SV3H712 AMP + Optical S/PDIF Out
Fitur Kemudahan Rakit & Diagnostik: PCIe Slot Q-Release (lepas GPU mudah), M.2 Q-Latch, BIOS FlashBack, Clear CMOS, Q-Code 2-digit Debug LED
Memori: 4x DDR5 DIMM (Dual Channel) DDR5, Max 192 GB (4x 48 GB) (DDR5-8000+ (OC) / AMD EXPO & Intel XMP)
Penyimpanan: 4x M.2 (2x PCIe 5.0 x4 + 2x PCIe 4.0 x4 with massive thermal armor), 4x SATA 6Gb/s (RAID 0, 1, 10)

Konektivitas: Intel 2.5GbE LAN + Wi-Fi 6E (802.11ax) + Bluetooth 5.3, 1x USB 3.2 Gen 2x2 Type-C, 1x USB 3.2 Gen 2 Type-C, 10x USB Type-A, HDMI 2.1, DisplayPort 1.4

Rilis: 2024-01-01
Sumber harga: Authorized Distributor Indonesia 2024-2026
Harga diperbarui: 2026-09-07
cpu bios update notes: Ryzen 8000/9000 may require BIOS update on a 600-series board; verify motherboard revision and CPU Support List.
cpu support generations: AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series
m2 slots detail: 2x PCIe 5.0 x4, 2x PCIe 4.0 x4 with massive thermal armor
memory max gb: 192
memory module form factor: UDIMM
memory registered support: no
memory slots total: 4
pcie slots detail: 2x PCIe 5.0 x16 (x16 or x8/x4 mode), 1x PCIe 4.0 x16 @ x4
