Kembali ke katalogGigabyte Z890 AORUS PRO ICE

Tag

motherboardgigabytelga1851z890thunderbolt4wifi7all-whiteaorus

TECHNICAL INDEX

Spesifikasi perangkat

Data teknis disusun per sistem agar lebih cepat dipindai dan dibandingkan.

Prosesor: Intel Z890 (LGA 1851), ATX (305 x 244 mm), VRM 16+1+2 Digital VRM (90A Smart Power Stage)
Socket CPU: LGA 1851
Chipset Kompatibel: Intel Z890
Form Factor Motherboard: ATX (305 x 244 mm)
Kecepatan RAM Maksimal: DDR5-8800+ MT/s (OC CUDIMM & UDIMM) / Intel XMP
Jumlah Port SATA: 4
Fasa VRM & Desain Daya: 16+1+2 Digital VRM (90A Smart Power Stage)
Konektor Daya CPU: 2x 8-pin EPS 12V
Tipe Memori (RAM): DDR5
Jumlah Slot DIMM: 4x DDR5 DIMM (Dual Channel, D5 Bionic Coba)
Kapasitas RAM Maksimal: 192 GB (4x 48 GB)
Slot Ekspansi PCIe: 1x PCIe 5.0 x16 (PCIe EZ-Latch Plus), 2x PCIe 4.0 x16 @ x4
Slot M.2 NVMe: 5x M.2 total (1x PCIe 5.0 x4 + 4x PCIe 4.0 x4 with All-White Thermal Guard)
Port SATA 6Gb/s: 4x SATA 6Gb/s
Port I/O Panel Belakang: 2x Thunderbolt 4 Type-C (40Gbps), 4x USB 10Gbps Type-A, 4x USB 5Gbps, HDMI 2.1
Jaringan (LAN & Wi-Fi): Realtek 2.5GbE LAN + Intel Wi-Fi 7 (320MHz) + Bluetooth 5.4
Subsistem Audio: Realtek ALC1220 7.1 HD Audio + Audio Noise Guard
Fitur Kemudahan Rakit & Diagnostik: PCIe EZ-Latch Plus, M.2 EZ-Latch Click, Q-Flash Plus, All-White Aesthetic Theme (PCB & Heatsink putih bersih)
Memori: 4x DDR5 DIMM (Dual Channel, D5 Bionic Coba) DDR5, Max 192 GB (4x 48 GB) (DDR5-8800+ MT/s (OC CUDIMM & UDIMM) / Intel XMP)
Penyimpanan: 5x M.2 total (1x PCIe 5.0 x4 + 4x PCIe 4.0 x4 with All-White Thermal Guard), 4x SATA 6Gb/s

Konektivitas: Realtek 2.5GbE LAN + Intel Wi-Fi 7 (320MHz) + Bluetooth 5.4, 2x Thunderbolt 4 Type-C (40Gbps), 4x USB 10Gbps Type-A, 4x USB 5Gbps, HDMI 2.1

Rilis: 2024-01-01
Sumber harga: Authorized Distributor Indonesia 2024-2026
Harga diperbarui: 2026-09-07
cpu bios update notes: Verify exact Core Ultra 200S CPU Support List and BIOS version; motherboard revision may affect support.
cpu support generations: Intel Core Ultra 200S Series
m2 slots detail: 1x PCIe 5.0 x4, 4x PCIe 4.0 x4 with All-White Thermal Guard
memory max gb: 192
memory module form factor: UDIMM
memory registered support: no
memory slots total: 4
pcie slots detail: 1x PCIe 5.0 x16 (PCIe EZ-Latch Plus), 2x PCIe 4.0 x16 @ x4
