Kembali ke katalogGigabyte B650 AORUS ELITE AX

Tag

motherboardgigabyteam5b650ddr5aorus

TECHNICAL INDEX

Spesifikasi perangkat

Data teknis disusun per sistem agar lebih cepat dipindai dan dibandingkan.

Prosesor: AMD B650 (Socket AM5 (LGA 1718)), ATX (305 x 244 mm), VRM 14+2+1 Twin Digital VRM Design (70A Smart Power Stage)
Socket CPU: Socket AM5 (LGA 1718)
Chipset Kompatibel: AMD B650
Form Factor Motherboard: ATX (305 x 244 mm)
Kecepatan RAM Maksimal: DDR5-8000+ (OC) / AMD EXPO & Intel XMP
Jumlah Port SATA: 4
Fasa VRM & Desain Daya: 14+2+1 Twin Digital VRM Design (70A Smart Power Stage)
Konektor Daya CPU: 1x 8-pin + 1x 4-pin EPS 12V
Tipe Memori (RAM): DDR5
Jumlah Slot DIMM: 4x DDR5 DIMM (Dual Channel)
Kapasitas RAM Maksimal: 192 GB (4x 48 GB)
Slot Ekspansi PCIe: 1x PCIe 4.0 x16 (PCIe EZ-Latch), 2x PCIe 3.0 x16 @ x1
Slot M.2 NVMe: 3x M.2 (1x PCIe 5.0 x4 CPU + 2x PCIe 4.0 x4 Chipset with Thermal Guard)
Port SATA 6Gb/s: 4x SATA 6Gb/s (RAID 0, 1, 10)
Port I/O Panel Belakang: 1x USB 3.2 Gen 2 Type-C (10Gbps), 2x USB 3.2 Gen 2 Type-A, 5x USB 3.2 Gen 1, 4x USB 2.0, DisplayPort 1.4, HDMI 2.1
Jaringan (LAN & Wi-Fi): Realtek 2.5GbE LAN + AMD Wi-Fi 6E + Bluetooth 5.3
Subsistem Audio: Realtek ALC897 7.1 HD Audio with High-End Audio Capacitors
Fitur Kemudahan Rakit & Diagnostik: Q-Flash Plus Button (update BIOS tanpa CPU), PCIe EZ-Latch, M.2 EZ-Latch, Pre-installed I/O Shield
Memori: 4x DDR5 DIMM (Dual Channel) DDR5, Max 192 GB (4x 48 GB) (DDR5-8000+ (OC) / AMD EXPO & Intel XMP)
Penyimpanan: 3x M.2 (1x PCIe 5.0 x4 CPU + 2x PCIe 4.0 x4 Chipset with Thermal Guard), 4x SATA 6Gb/s (RAID 0, 1, 10)

Konektivitas: Realtek 2.5GbE LAN + AMD Wi-Fi 6E + Bluetooth 5.3, 1x USB 3.2 Gen 2 Type-C (10Gbps), 2x USB 3.2 Gen 2 Type-A, 5x USB 3.2 Gen 1, 4x USB 2.0, DisplayPort 1.4, HDMI 2.1

Rilis: 2024-01-01
Sumber harga: Authorized Distributor Indonesia 2024-2026
Harga diperbarui: 2026-09-07
cpu bios update notes: Ryzen 8000/9000 may require BIOS update on a 600-series board; verify motherboard revision and CPU Support List.
cpu support generations: AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series
m2 slots detail: 1x PCIe 5.0 x4 CPU, 2x PCIe 4.0 x4 Chipset with Thermal Guard
memory max gb: 192
memory module form factor: UDIMM
memory registered support: no
memory slots total: 4
pcie slots detail: 1x PCIe 4.0 x16 (PCIe EZ-Latch), 2x PCIe 3.0 x16 @ x1
