TECHNICAL INDEX

Spesifikasi perangkat

Data teknis disusun per sistem agar lebih cepat dipindai dan dibandingkan.

Prosesor: AMD B650 (Socket AM5 (LGA 1718)), Micro-ATX (244 x 244 mm), VRM 8+2+1 Duet Rail Power System (60A DrMOS)
Socket CPU: Socket AM5 (LGA 1718)
Chipset Kompatibel: AMD B650
Form Factor Motherboard: Micro-ATX (244 x 244 mm)
Kecepatan RAM Maksimal: DDR5-7200+ (OC) / AMD EXPO & Intel XMP
Jumlah Port SATA: 4
Fasa VRM & Desain Daya: 8+2+1 Duet Rail Power System (60A DrMOS)
Konektor Daya CPU: 2x 8-pin EPS 12V
Tipe Memori (RAM): DDR5
Jumlah Slot DIMM: 4x DDR5 DIMM (Dual Channel)
Kapasitas RAM Maksimal: 192 GB (4x 48 GB)
Slot Ekspansi PCIe: 1x PCIe 4.0 x16 (Steel Armor), 1x PCIe 4.0 x16 @ x4, 1x PCIe 3.0 x1
Slot M.2 NVMe: 2x M.2 (both PCIe 4.0 x4 with M.2 Shield Frozr)
Port SATA 6Gb/s: 4x SATA 6Gb/s (RAID 0, 1, 10)
Port I/O Panel Belakang: 4x USB 3.2 Gen 2 (termasuk Type-C), 4x USB 3.2 Gen 1, HDMI 2.1, DisplayPort 1.4
Jaringan (LAN & Wi-Fi): Realtek 2.5GbE LAN + Wi-Fi 6E + Bluetooth 5.3
Subsistem Audio: Realtek ALC897 7.1 HD Audio
Fitur Kemudahan Rakit & Diagnostik: Flash BIOS Button, EZ Debug LED, Steel Armor PCIe
Memori: 4x DDR5 DIMM (Dual Channel) DDR5, Max 192 GB (4x 48 GB) (DDR5-7200+ (OC) / AMD EXPO & Intel XMP)
Penyimpanan: 2x M.2 (both PCIe 4.0 x4 with M.2 Shield Frozr), 4x SATA 6Gb/s (RAID 0, 1, 10)

Konektivitas: Realtek 2.5GbE LAN + Wi-Fi 6E + Bluetooth 5.3, 4x USB 3.2 Gen 2 (termasuk Type-C), 4x USB 3.2 Gen 1, HDMI 2.1, DisplayPort 1.4

Rilis: 2024-01-01
Sumber harga: Authorized Distributor Indonesia 2024-2026
Harga diperbarui: 2026-09-07
cpu bios update notes: Ryzen 8000/9000 may require BIOS update on a 600-series board; verify motherboard revision and CPU Support List.
cpu support generations: AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series
m2 slots detail: both PCIe 4.0 x4 with M.2 Shield Frozr
memory max gb: 192
memory module form factor: UDIMM
memory registered support: no
memory slots total: 4
pcie slots detail: 1x PCIe 4.0 x16 (Steel Armor), 1x PCIe 4.0 x16 @ x4, 1x PCIe 3.0 x1
